Carbon Shipbuilding Steel Plate

Shipbuilding steel plate refers to the carbon and alloy steel plate used in offshore and marine contructions, common grades are A, B, D, E, AH32/36/40, DH32/36/40, and EH32/36/40 which ranged from different strength.

WhatsApp: +86 18015371666

Email: jack@huiyingsteel.com

Product Description

Carbon Shipbuilding Steel Plate Description

Shipbuilding steel plate refers to hot-rolled steel for the manufacture of ship structures produced in accordance with the requirements of the construction society. Often used as a special steel ordering, scheduling, sales, a ship including ship plates, steel and so on.

The Shipbuilding steel plate can be divided into general strength structural steel and high strength structural steel according to its minimum yield point strength level.

AGICO supplies and exports 2 types of ship steel, medium strength shipbuilding plate and high strength shipbuilding plate. All steel plate product can be manufactured according to Society LR, ABS, NK, GL, DNV, BV, KR, RINA, CCS, etc.

Product Parameters

Product Name	Carbon Shipbuilding Steel Plate
Production Process	Hot Rolling, Cold Rolling
Material Standards	AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.
Width	100mm-3000mm
Length	1m-12m, or Customized Size
Thickness	0.1mm-400mm
Delivery Conditions	Rolling, Annealing, Quenching, Tempered or Standard
Surface Process	Ordinary, Wire Drawing, Laminated Film

Chemical Composition

Grade	C % ≤	Mn %	Si %	P % ≤	S % ≤	Al %	NB %	V %
A	0.22	≥ 2.5 C	0.10-0.35	0.04	0.40	-	-	-
B	0.21	0.60-1.00	0.10-0.35	0.04	0.40	-	-	-
D	0.21	0.60-1.00	0.10-0.35	0.04	0.04	≥ 0.015	-	-
E	0.18	0.70-1.20	0.10-0.35	0.04	0.04	≥ 0.015	-	-
A32 D32 E32	0.18	0.70-1.60 0.90-1.60 0.90-1.60	0.10-0.50	0.04	0.04	≥ 0.015	-	-
A36 D36 E36	0.18	0.70-1.60 0.90-1.60 0.90-1.60	0.10-0.50	0.04	0.04	≥ 0.015	0.015-0.050	0.030-0.10

Mechanical Properties

Grade	Thickness (mm)	Yieldpoint (Mpa) ≥	Tensile Strength (Mpa)	Elongation (%) ≥	V-impact Test			Cold Bend Test
					Temperature (℃)	Average AKV A kv /J		b=2a 180°	b=5a 120°
						Lengthways	Crosswise
						≥
A	≤ 50	235	400-490	22	—	—	—	d=2a	—
B					0	27	20	—	d=3a
D					-10
E					-40
A32	≤ 50	315	440-590	22	0	31	22	—	d=3a
D32					-20
E32					-40
A36	≤ 50	355	490-620	21	0	34	24	—	d=3a
D36					-20
E36					-40

Product Application

Chemical Industry

steel is used to construct facilities such as large storage tanks, refining equipment, and chemical pipelines.

Natural Gas Industry

Steel is also widely used in the energy industry, such as oil and gas pipelines.

Oil Pipeline

In the oil and gas industry, carbon steel is used to manufacture various equipment and pipelines.

Ship

In shipbuilding, steel is used to manufacture key components such as ship structures and engine parts.

Stadium

Steel plays an important role in steel structure buildings such as high-rise buildings, large-span buildings, and sports venues.

Water Treatment

The application of steel in water treatment is mainly reflected in the construction of water treatment equipment and the production of components such as pipelines.

Packaging and shipping

Factory Display

FAQ

Q1: What metal materials do you supply?

Jiangsu Zhongersheng is a professional manufacturer mainly supplying carbon steel, hot-dip galvanized steel, PPGI color coated steel, 201/304/316 stainless steel sheets, coils, tubes and profiles, as well as various steel structural parts. Our products serve infrastructure, photovoltaic, machinery manufacturing, chemical and new energy industries.

Q2: Can you customize material grades, thickness and sizes?

Full customization is available. For carbon steel, galvanized steel and stainless steel, thickness, width and length can be adjusted in accordance with ASTM & EN standards. Profiles can be cut and processed as per drawings, and special steel materials can be customized via production line scheduling.

Q3: What’s the difference between galvanized steel and color coated PPGI?

Hot-dip galvanized steel features pure zinc anti-rust coating with cost-effective and wear-resistant performance, suitable for steel brackets, guardrails and load-bearing structures, and supports secondary painting. PPGI takes galvanized sheet as base material with colorful coating for anti-rust & decorative purposes, widely used for factory roof/wall panels and energy storage housings. Thick galvanized steel is recommended for rainy coastal areas, while PPGI is ideal for decorative outdoor projects.

Q4: Do you have spot inventory? What’s your MOQ?

We built a 10,000-ton standardized warehouse with abundant spot stock of carbon steel, galvanized steel and stainless steel. MOQ is 1 ton for standard sizes; small samples of dozens of kilograms are acceptable. No upper limit for bulk engineering orders, mixed container loading of multiple steel types is supported.

Q5: How long is the delivery time for spot goods & customized goods?

Spot goods can be loaded within 3-7 days; simple cutting & bending processing orders take 7-10 days; mould opening & special steel customization takes 15-30 days, subject to specific specifications confirmation.
